Crossing Thermal Twist Injector (Ball-less) Terp Hammer Kit


Crossing Thermal Twist Injector (Ball-less) Terp Hammer Kit


Removing the need for balls entirely we have designed this with vortex airflow and a metal core! Available in either SS316 Stainless Steel or Grade 2 Titanium. The Vortex airflow removes the need to stir your bowl when used with around 0.1.5-0.2g loads as the hot air does the work for you, removing one additional step while vaping! Just load in a one SQP of herb, place the housing on the bowl, inhale, then watch it spin up and settle in to place! There's no need to tamp your bowl as the airflow will do this for you! Due to the spinning airflow the Thermal Twist also makes an excellent micro-doser, happily vaporizing down to around 0.05g (we haven't tested with less... it would still vape less).

Designed with a simplified user experience in mind, the Thermal Twist comes fully set up with a handle installed on the heater coil and the housing fully set up, making for a plug and play experience without the possibility of spilling balls (as there are none) or mis-installing the handle during setup! Plug the heater into the front of the PID, the power adapter/plug into the back, turn it on, set your temp and it's ready to go (initial burn off cycle advisable)! The Stand has been designed to provide minimal contact with the housing, meaning the heat stays where it should be, inside the housing and not being transferred into your stand, or worse, into the surface below!

Capable of providing anything between low temp terpy hits, to thick clouds. The Thermal Twist has fairly fast vapor production and exceptionally smooth vapor!

This kit comes with everything needed to get started, aside from a glass Rig or Bubbler (optionally available) and herb.

Suggested set temperature range on the PID: 280- 390c (526f-734f) but as with everything... use it as you like it!

Titanium provides slightly better flavor and is a lighter weight material
Stainless Steel provides slightly smoother vapor


Thermal Twist Injector (Choose 316 Stainless Steel or GR2 Titanium)
Crossing Technology Micro PID (1c/1f) (CE/ROHS Certified)
20mm Heater Coil with Silicone Handle Pre-installed (220v)
Pre-installed Heat Guard for the Thermal Twist Housing
Glass Bowl with a Side-Carb (approx. 0.4g max capacity) - 14.4mm Male Joint Bowl
14.4mm to 18.8mm Male Adapter
Keck Clip
Steel Stand
SQP - Scoop and Tamper
Wood Cleaning Brush
Spare Screens
Power Cord
Instructions Sheet

Warranty Info

We provide a one year warranty on the PID controller and Heater Coil.
Broken glassware should be reported on arrival.

Usage notes

If using the 14mm bowl with the keck clip and 18mm adapter, when you install the 14mm bowl into the 18mm joint give it a little push and twist to help the two joints lock together, then install the keck clip. This will help prevent the joints rotating unintentionally
Unless using this setup with the diffuser bowl (not included, coming soon) it is not advisable to leave the Thermal Twist housing on the bowl. Place the housing on the bowl, inhale, remove the housing setup and place it safely on the stand
To avoid the herb being additionally compacted there is a side carb/stopper integrated into the bowl, you can remove this stopper to assist in clearing the bubbler of excess vapor
The Heat Guard extends past the bottom of the injector housing for maximum protection, this also helps align the bottom of the injector housing into your bowl for added convenience and makes it very hard to miss! We only mention this as those of you who are already using injector vapes will be unused to this system as with most devices you have to watch closely to ensure the injector is neatly placed into the bowl.

Please perform a burn off cycle on the housing before installed. Once set up, set your PID to 390C (734f) and allow any manufacture residues to burn off. Give it 5 minutes before first use.

Fun features

The Thermal Twist can be used with the 18mm C/C Quartz Cap vaporizer by the rogue wax works. Just pop the housing over the top of the glass chamber section and use your Quartz Cap vaporizer as a diffuser style bowl! With or without heat soak! If heat soaking you can adjust the mesh screen inside the Quartz Cap chamber so that it sits higher up for a full hybrid experience. You will want to reduce the temps on your pid by around 70-100c if doing this.
